Details

MACHINE PARAMETERS:

MODEL RANGE:TA-[200~355][A\W]/[7~1.25]EPM

PRESSURE:0.7~1.25Mpa

EXHAUST VOLUME:29.05~65.34m3/min

POWER:200~355kw

COOLING METHOD: AIR OR WATER

PRODUCT ADVANTAGES:

1. The new generation high-efficiency energy-saving host independently developed anddesigned by Tecbell, with optimized design of the rotor profile and exhaust port structure, usescontact surfaces, contact lines, and leakage triangle areas to achieve optimal performance andimprove volumetric efficiency.

2. The high-efficiency motor with low temperature rise and high torsional strength, combinedwith excellent screw rotors, can reduce the life cycle cost of the compressor, significantlyimproving the energy-saving effect by 15% compared to the previous generation of products.

3. The patented independent closed suction and exhaust cooling system, as well as theintegrated air filter assembly filtration system, ensure that the internal temperature andsuction temperature of the unit are close to the ambient temperature, resulting in lowelenergy consumption.

4. A patented temperature control system that accurately controls oil temperature; Thetemperature control valve with flange connection makes the internal oil circuit connection ofthe unit more concise and firm, reducing pressure drop, leakage points, energy consumption.and fault occurrence rate of the unit.

5. The low speed centrifugal fan and the plate fin heat exchanger cooling system designed withlarge waste heat make it more stable to operate in harsh operating environments, loweroperating costs,and longer service life.

6. High efficiency Permanent magnet variable-speed synchronous motor is adopted, and themotor with F class insulation,B class temperature rise, increased base number and IP55protection level is optimized for air compressor application, with motor efficiency up to 96.8%

7.The dual frequency conversion control system combining high-performance frequencyconverters with innovative design of permanent magnet motor technology has a significantenergy-saving effect on the unit.

8. Multiple additional protection for constant temperature and pressure output, intelligentcontrol and display, standard loT, remote monitoring, and intelligent display of operatingconditions.

9. The whole series of machines exceed Energy efficiency level-1
